Victron MultiPlus-II Inverter/Charger (12V 230V / 3000VA / 120-32A)

£1416.99(inc VAT) £1841.99
View delivery optionsView product description
  Product Description
Let's discuss the Victron MultiPlus-II Inverter/Charger. This versatile device merges the capabilities of the MultiPlus and the MultiGrid, with the added advantage of an external current transformer to optimise self-consumption with external current sensing. It boasts PowerControl and PowerAssist features, so it avoids overload of a limited power supply like generators.

One of its striking qualities, the Victron MultiPlus-II forms an integral component of the Victron Energy Storage Systems (ESS), complementing MPPT Solar Chargers or Grid-tie PV Inverters. Acting as an uninterrupted power supply, it guarantees a smooth operation of electronic gear without any disruption, courtesy of its ultra-fast switching feature.

For tech-savvy users, the Victron MultiPlus-II can be remotely controlled through the VRM app and portal website, providing complete control over your system via phone, tablet, laptop, or PC. Moreover, it's excellent for auto-starting a backup generator for power emergencies.

In technical terms, the Victron MultiPlus-II contains a transfer switch rated at 32A, max AC input current of 32A and a max. battery charge current of 120A. It features an advanced auxiliary output and programmable relay along with a remote on-off functionality. Furthermore, there's a flexibility of battery-connection with M8 bolts 230V AC-connection, making it an ideal choice for all range of users!

Victron MultiPlus-II Inverter/Charger (12V 230V / 3000VA / 120-32A) Features


  • PowerAssist
  • PowerControl
  • ESS: Energy Storage Systems
  • Uninterrupted AC power (UPS)
  • Remote Monitoring & Control
  • MultiPlus & MultiGrid Functions

Specifications
  • Charger Short Circuit Protection : Yes
  • Frequency Description : Charger Input: 45-65Hz, Inverter Output: 50Hz ± 0.1%
  • Type : 12V Inverter / Chargers
  • Voltage Description : Charger Input: 187-265V AC, Inverter Input: 9.5-17V DC, Inverter Output: 230V AC ±2%
  • Rating : IP22
  • Height Description : 546mm
  • Width : 268mm
  • Depth : 147mm
  • Weight : 19kg
  • Material : Steel (blue RAL 5012)
  • Wattage : Output @ 25°C: 2400W, Output @ 40°C: 2200W, Output @ 65°C: 1700W
  • Approvals : EN-IEC 60335-1, EN-IEC 60335-2-29, EN-IEC 62109-1, EN-IEC 62109-2, EN 55014-1, EN 55014-2, EN-IEC 61
  • Operating Temperature : -40°C to +65°C
  • Amps Description : Charger: 120A / Transfer Switch: 32A
  • Style : Combined Inverters & Battery Chargers
