Fiamma Recessed Floor Base for Table Leg

£14.43(inc VAT) £17.99
?
View delivery optionsView product description
Fiamma Recessed Floor Base for Table Leg
Fiamma Recessed Base Plug for Tables
Only  £17.34
Save £0.91

Fiamma Recessed Floor Base for Table Leg
Fiamma Recessed Base Plug for Tables
Only  £17.34
Save £0.91

  Product Description
The Fiamma Recessed Floor Base (Fiamma code C0331-01-) is the floor-mounted connection point that forms the foundation of the Fiamma modular table leg system. Made from anodised aluminium, the base sits flush with the floor with the socket recessed below floor level, giving a clean, professional finish used by caravan, motorhome, campervan and boat builders. Overall diameter is 110mm, with an internal pole diameter of approximately 58mm to accept the Fiamma Tube Pro table leg. To fit it you'll need to cut a hole 65mm in diameter and 50mm deep, then secure the base with the supplied self-tapping screws. It's 0.1kg, so it adds virtually nothing to vehicle weight.

What's the difference between a recessed and above-floor table base for a caravan or motorhome?


The recessed base sits flush with the floor with the socket below floor level, requiring a 65mm diameter x 50mm deep cut-out. The above-floor (conic) base screws directly onto the surface with no cutting required. The recessed option gives a neater look with no trip hazard when the table is not in use, and accepts the Fiamma Tube Pro leg at approximately 58mm internal diameter.

This base is part of the wider Fiamma modular table system, which means the same Tube Pro table leg can be used indoors with either the recessed or conic surface mount, or taken outside and fitted to the freestanding Tripod Pro base. It's a smart setup for anyone who wants a proper dining table inside the van that comes down quickly and stows completely out of the way. The anodised finish resists corrosion, and the current production version has a granular feel with a glitter effect rather than the older shiny chrome appearance. When the table is removed, a plastic Fiamma cap (sold separately, code 134298 / Fiamma ref 02411-01B) presses into the socket to keep debris out and cover the hole neatly.

Replacement of a worn or damaged recessed base in an existing van is a common reason to buy this part, and it's also a popular choice for campervan conversions where a fixed-position dining table is being built in from scratch. Fitting is straightforward: mark and cut the floor to size, drop the base in, and fix it down with the six self-tapping screws that come in the box. It's worth pairing with the Fiamma Tube Pro 70cm leg and a suitable conic connection or table top to complete the setup.

Fiamma Recessed Floor Base for Table Leg Features


  • Aluminium table floor socket for Tube Pro leg.
  • Overall diameter: 110mm.
  • Fits legs of 57mm.
  • Supplied with self-tapping screws.


Associated Products
Quick View     Fiamma Above Floor Base for Table Legs - Conic Connection

Quick View     Fiamma Table Tripod Pro Base (Base only)

Quick View     Fiamma Tube Pro Table Leg 70cm

Quick View     Fiamma Recessed Base Plug for Tables

Quick View     Fiamma Adaptor for Tube Pro 70 (98655-605)


Frequently Asked Questions


What size hole do I need to cut for the Fiamma Recessed Floor Base?
You need to cut a hole 65mm in diameter and 50mm deep in the floor. The base itself has an overall diameter of 110mm, so the outer flange sits over the cut-out and is secured to the floor surface with the supplied self-tapping screws. The internal pole diameter is approximately 58mm to accept the Fiamma Tube Pro table leg.
Which table leg fits the Fiamma Recessed Floor Base?
The Fiamma Recessed Floor Base (C0331-01-) is designed for use with the Fiamma Tube Pro table leg, which has a 57mm diameter pole. It is part of the Fiamma modular table system. The same Tube Pro leg can also be used with the above-floor Conic Connection base or the freestanding Tripod Pro base, meaning the table top and leg can be transferred between indoor and outdoor positions.
What is the Fiamma product code for the recessed floor base?
The Fiamma product code is C0331-01-. The EAN-13 barcode is 8004815010331. This is the standard recessed connection used across the Fiamma modular table system for caravans, motorhomes, campervans and boats.
What covers the hole in the floor when the table is not in use?
The Fiamma Recessed Base Plug (code 02411-01B / 134298) is a grey plastic cap that presses into the socket to cover the hole and keep out dirt and debris when the table leg is removed. It is sold separately and measures approximately 50mm in diameter to fit the socket opening.
What material is the Fiamma Recessed Floor Base made from?
The base is made from anodised aluminium. Anodising hardens the surface and protects against corrosion and scratching, making it suitable for the floor environment inside a caravan, motorhome or campervan. The current production version has a granular texture with a glitter effect finish, replacing the earlier shiny chrome appearance.
Can the Fiamma recessed base be used in a campervan conversion?
Yes. The Fiamma Recessed Floor Base is widely used in campervan conversions where a permanent dining table position is being built in. It allows the table to be set up and removed quickly, and the flush fitting means there is no protrusion above the floor when the leg is out. The base is also used in boats and horseboxes as well as factory-built caravans and motorhomes.
Does the Fiamma Recessed Floor Base come with fixing screws?
Yes, six self-tapping screws are included in the box. These are used to secure the base flange to the floor once the cut-out has been made. No additional fixings are required for the base installation itself, though the Fiamma Tube Pro table leg and a conic connection or table top are sold separately to complete the setup.
What is the difference between the Fiamma recessed and conic (above-floor) table base?
The recessed base is fitted below floor level with the socket flush to the floor surface, requiring a 65mm x 50mm cut-out. The conic (above-floor) base sits on top of the floor and is screwed down without any cutting. The recessed type gives a neater appearance and eliminates any raised edge that could become a trip hazard, while the conic base is quicker to install and suitable where floor cutting is not an option.
EAN-13 : 8004815010331

1 Customer Review on Fiamma Recessed Floor Base for Table Leg

Boat Renovation

<span style='color:gray;'>by Robert (18 Apr 2017)</span>
5 star review(5/5)
These are very well made and smaller than others available . They look very neat and are easy to fit.
