Fiamma F45S & F45L Box Rafter Support

£11.77(inc VAT) £13.99
View delivery optionsView product description
  Product Description
The Fiamma F45S Box Rafter Support (part number 98655-542) is the two-part bracket that sits inside the awning case body and gives the Fiamma Rafter and Rafter Pro their mounting point on F45S, F45L, F45 Ti L, F45 iL and F70 awnings. Without it, you simply can't attach a rafter properly to the case end of the awning at all. It's a genuine Fiamma spare part, so it matches the original fixing exactly rather than requiring any modification to get it seated correctly.

What is the difference between the Fiamma Box Rafter Support and the Pelmet Rafter Support for the F45S?


The Box Rafter Support (98655-542) is the two-part bracket that fits inside the awning case itself, providing the hook-in point at the case (vehicle) end of the rafter. The Pelmet Rafter Support (98655-554) is a separate part that attaches to the rear of the Lead Bar at the front of the awning. A complete rafter installation on an F45S requires both supports working together.

People tend to need this part in two situations. The first is when the original bracket has snapped or gone missing, which does happen on older awnings that have had the rafter fitted and removed repeatedly over the years. The second is when someone is adding a Rafter or Rafter Pro to an F45 awning for the first time and the original case-side bracket is absent. It's a small but specific component, and getting the correct Fiamma part number matters because the geometry of the hook engagement is precise.

This bracket fits F45S awnings from 260cm to 450cm in length, and also covers the F45L from 450cm to 550cm. If you're running a Fiamma Rafter to solve the classic problem of water pooling on the canopy in rain, or the constant flapping that makes longer awnings uncomfortable in any breeze, this support is the piece that gets the case end of that rafter securely anchored. If you're unsure whether your awning already has one fitted, open the case and look for the bracket sitting centrally inside the box body - it's the part the rafter hook clips onto.

Frequently Asked Questions


What awning models does the Fiamma Box Rafter Support 98655-542 fit?
The Fiamma Box Rafter Support 98655-542 is compatible with Fiamma F45S awnings from 260cm to 450cm in length, Fiamma F45L awnings from 450cm to 550cm, Fiamma F45 Ti L, Fiamma F45 iL and Fiamma F70 awnings. It is not compatible with the F45 Zip or other Fiamma awning ranges such as the F35 Pro, F65 or F80.
What is the difference between the Fiamma Box Rafter Support and the Pelmet Rafter Support?
The Box Rafter Support (98655-542) is a two-part bracket that fits inside the awning case body itself, at the vehicle end of the awning. It provides the hook-in mounting point for the rafter arm within the case. The Pelmet Rafter Support (98655-554) is a separate component that attaches to the rear face of the Lead Bar at the front (outer) end of the awning. A standard Fiamma Rafter installation on an F45S awning uses both parts: the Box Rafter Support at the case end and the Pelmet Rafter Support at the lead bar end.
Do I need the Box Rafter Support to fit a Fiamma Rafter to my F45S awning?
Yes. The Fiamma Rafter and Rafter Pro both hook into this bracket inside the awning case at the vehicle end. Without a Box Rafter Support in place, the rafter has nothing to attach to at the case end and cannot be correctly installed. Some F45S awnings are supplied with this bracket already fitted inside the case. If yours is missing or damaged, part 98655-542 is the correct replacement.
Is the Fiamma Box Rafter Support 98655-542 compatible with the Fiamma Rafter Pro as well as the standard Rafter?
Yes. The Box Rafter Support 98655-542 is designed to accept both the standard Fiamma Rafter and the Fiamma Rafter Pro. Both products use the same hook-in connection point at the case end of the awning, so the bracket is compatible with either version.
How do I know if my F45S awning already has a Box Rafter Support fitted?
Open the awning case and look inside the box body centrally along its length. The Box Rafter Support is a small two-part plastic and metal bracket seated inside the case interior. If you can see a bracket with a hook receiver point, the support is already in place. If the interior of the case is bare at that point, or if the bracket is visibly cracked or broken, you will need to fit a replacement 98655-542.
Why would the Fiamma Box Rafter Support need replacing?
The most common reasons are physical damage from repeated rafter installation and removal over several seasons, cracking from UV exposure or cold weather brittleness, or the bracket going missing during a previous repair or case removal. Because the bracket sits inside the case, it is not visible during normal use, so damage can go unnoticed until the rafter no longer hooks in securely.
EAN-13 : 8004815288068

1 Customer Review on Fiamma F45S & F45L Box Rafter Support

Rafter Support Bracket

<span style='color:gray;'>by mr p price (28 May 2025)</span>
5 star review(5/5)
very prompt service. dealt with questions about delivery very promptly and professionaly support bracket good quality
