2 Technical Questions on the Truma Temperature Control Device Ultraheat
I have a truma ultraheat fire in my 9 year old autosleeper motorvan When I use the wall switch on any of the 3 settings the van warms to a very comfortable heat then clicks off and will not switch itself on again till the van has gone back to being very cold, What could this be please.
by Colin Sutton
This is probably the thermostat that is the problem. This is our part 133317 and would be the first item to replace.
i have a bailey ranger 2006 500sieres blow air not getting hot on electric ok on gas why
by e b Johnson
You will need to access the printed circuit board that is situated behind the heater at floor level. Check the continuity between the two black wires. If no continuity then temperature limiter, our ref 133316, is faulty and needs replacing. If OK then check the continuity between the green and blue wires. If no continuity then thermostat, our ref 133317 is faulty and needs replacing. If this is OK then there may be a fault with the printed circuit board itself, our part 133335, and the replacing of this may solve the problem. If not then it is possible that the heating element itself, part 137342, has broken and a new one will need to be fitted. You may need to seek the help of an electrician who will have the equipment to test the items.
7 Customer Reviews on Truma Temperature Control Device Ultraheat
by MR.L THIRD (27 Apr 2016)
Service excellent, goods arrived the next day, fitted that day and the fire is now working.
Nice Warm Caravan
by Paul (27 Sep 2014)
Suggest that the temperature limiter changed at same time.
Just The Job
by Pete (04 Dec 2013)
Super service would recommend this company to all.
Part ordered Sunday arrived Tuesday fitted and working Tuesday evening.
Easy to use web site others could learn from this company.
Did The Job
by JB (08 Feb 2013)
Truma gas/elec heater wouldn't work on elec. Took apart and found temp control device burned out. Replaced along with limit sensor. And O ring for flue connector.
Item Fitted But Did Not Cure Fault
by Mr Hilson (24 Jan 2013)
I ordered wrong item, see my report on "Truma Control Panel Cable - 5M." which does cure the problem. Leisureshop Direct, as always, performed well.
Leisureshopdirect.com To The Rescue
by F0ggy (06 Jun 2012)
My Caravan electric heater stopped working while we were on holiday in May.The temperature control device had failed. Found part and part number off their pdf files.Part was delivered within three working days.I now have a nice warm van again.Excellent Service all round.
It Is Cold Without The Heating
by Alan T (13 May 2011)
My heater failed while away in march ordered the parts beginning of may arrived within 5 days warm again
