1 Technical Question on the Truma Temperature Limiter Ultraheat
i have a bailey ranger 2006 500sieres blow air not getting hot on electric ok on gas why
by e b Johnson
You will need to access the printed circuit board that is situated behind the heater at floor level. Check the continuity between the two black wires. If no continuity then temperature limiter, our ref 133316, is faulty and needs replacing. If OK then check the continuity between the green and blue wires. If no continuity then thermostat, our ref 133317 is faulty and needs replacing. If this is OK then there may be a fault with the printed circuit board itself, our part 133335, and the replacing of this may solve the problem. If not then it is possible that the heating element itself, part 137342, has broken and a new one will need to be fitted. You may need to seek the help of an electrician who will have the equipment to test the items.
7 Customer Reviews on Truma Temperature Limiter Ultraheat
Temperature Switch - Limiter S3002 / 4
by C.W. (02 Nov 2016)
good item worked fine - however poorly identified. This could easily be mistaken for the other limit switch that sits next to it on the fire control plate. Flimsy securing wings which are easily bent - take care. Lugs can snap off if over bent or twisted - take care.
by Paul (27 Sep 2014)
suggest that temperature control device is changed at same time.
by Mr Potts (02 May 2013)
a difficult spare to find,butthis supplier stocked and dispatched the items quickly and with great care. Costs were very reasonable. I received the items within 3days of order. I would certainly use this supplier again.
Did The Job
by JB (08 Feb 2013)
Truma gas/elec heater wouldn't work on elec. Took apart and found temp control device burned out. Replaced along with limit sensor. And O ring for flue connector.
Item Fitted But Did Not Cure Fault
by Mr Hilson (24 Jan 2013)
I ordered wrong item, see my report on "Truma Control Panel Cable - 5M." which does cure the problem. Leisureshop Direct, as always, performed well.
Truma Ultraheat 175 Degree Temp Switch
by Mr Lawson (12 May 2012)
175 degree temp cutout for Truma Ultra heat purchased. Excellent service. recieved within 3 days.
What A Great Service
by Alan T (13 May 2011)
Exactley what i needed nice and warm again great price and great delivery times
