Truma S3004 Gas Heater

£180.89 - £495.35 (inc VAT)
BRAND : Truma
...or see our finance option(s)   Pay later with Klarna. Now available to all our customers.'
Next day delivery available on certain items - make selection for confirmation
?
View delivery optionsView product description
Trumatic S3004A Auto ignitor (without cover)
Front Cover for Truma S3004 Fire - Titanium Grey
Only  £678.59
Save £9.64
Add Bundle
  Free Shipping
Trumatic S3004A Auto ignitor (without cover)
Front Cover for Truma S3004 Fire - Titanium Grey
Truma Roof Flue Kit for the S3002 & S3004 heaters
Only  £811.61
Save £16.64
Add Bundle
  Free Shipping
  Loading...
The Truma S3004 Heater has an elegant design to match the furniture environment of modern caravans and motorhomes.

Simply switch it on for a comfortable temperature: Truma S 3004 heaters provide warmth and comfort within a very short time. The caravan and motor home heater is not only especially powerful, it is also extremely reliable – even at very low temperatures in winter. To heat your caravan even faster, the fan is equipped with a booster function.

Your caravan / motorhome not only becomes warm: the interior air is also dehumidified. At night, you can switch off the fan so that you can sleep undisturbed. Truma S 3004 heaters have a modern design and are easy to operate. The Truma S 3004 has a burner and a heat exchanger and is suitable for installation in caravans and motor homes.

Truma S heaters are easy to operate, are extremely reliable and have been popular for decades. The Truma S 3004 can be installed in caravans or motor homes.

Space-saving: Perfectly integrated into the interior design – thanks to the flat cover and modern look.
Independent: Can be operated without power supply and while driving.

Please note, for new installations you will also require an installation Truma flue kit. Please see the bundles for more information.

Truma S3004 Gas Heater Features


  • Booster function for 20% more volumetric air flow
  • Ergonomic control units with non-slip surface
  • Efficient, robust and low maintenance
  • Heating without electricity while you’re driving
  • Optimum integration in the interior thanks to the flat cover
  • Infinitely adjustable temperature and fan speed
  • Pleasant radiated warmth

Specifications

  • Energy sources : Propane / butane
  • Efficiency: approx. : 95%
  • Operating pressure : 30 mbar
  • Rated heat output : 3500 W
  • Fuel consumption : 30 – 280 g/h
  • Power consumption : 225 mW (ignition)
  • Operating voltage : 1.5 V (automatic ignition device with battery operation)
  • Weight : approx. 10.3 kg
  • Dimensions (L x W x H) : 373 x 503 x 545 mm
  • Installation cut-outs (L x W x H) : 280 x 480 x 480 mm


Truma S3004 Heater Graphical Setup

SAFETY NOTICE:

All products and parts must be installed by engineers who hold a valid certificate of competence. The installation must comply with the manufacturers instructions and local regulations. We cannot be held responsible if these instructions are not followed.

Please note we are a camping, caravan and motorhome company and NO gas product that we sell is suitable for mains (domestic) gas supply.

Further Information

16 FAQs on the Truma S3004 Gas Heater/Fire

Question

Does the heat exchanger of a Truma S3004 LPG heater have to be replaced after a certain time?

Answer

No.

Neither the European Heating Appliance Directive 2006/119/EC nor the international directive UN ECE R122 specify replacement.

In the 1990s there was a German regulation which specified that heat exchangers had to be replaced after ten years. For Truma heaters manufactured and put into operation during this time, the replacement obligation was prolonged to 30 years. The European Heating Appliance Directive no longer specifies replacement for appliances approved after 06/2005.

The E1 mark on the type plate shows whether your heater is approved in accordance with the European Heating Appliance Directive and, consequently, was manufactured after 06/2005.


Question

Can a Truma S3004 heater also be installed, for example, in a portacabin, etc.?

Answer

No.

Our heaters are not approved for use outside caravanning. Truma heaters may be installed only in Class O vehicles. The vehicle class can be found on the type approval in the certificate of registration.

If you have an S heater installed in a different vehicle class and it breaks down, it cannot be replaced with a new S heater.


Question

Can Truma heaters also be installed in mobile homes?

Answer

No.

Approvals for fixed buildings have changed so that Truma heaters cannot be installed in mobile homes. Our appliances are approved for recreational vehicles.

Heaters that are already installed are protected by a grandfather clause.


Question

May I install a Truma heater in the awning?

Answer

No.

Our current appliances are approved only for recreational vehicles. Therefore, installation in an awning is unfortunately not allowed.

But you can retrofit your Truma heater with an awning warmer. This directs the warm air from the existing caravan heater directly into the awning.

Heaters that are already installed are protected by a grandfather clause.


Question

Can a Truma S3004 heater also be operated while I’m driving?

Answer

Yes, heating while driving is possible with Truma Combi and VarioHeat heaters.

With Truma S and Trumatic S heaters, operating the heater while driving is possible only with a cowl top, which must be installed freely in the air flow. Truma recommends the cowl tops T-3 or T-2. Otherwise the flame can blow back and cause damage to the heater.

The cowl top must protrude at least 10 cm above roof attachments, such as roof boxes, ski or luggage racks so that the heater works properly.

For heating while driving, Directive UN ECE R 122 for motor homes and caravans specifies a safety shut-off device. The Truma MonoControl CS gas pressure regulation system fulfils this requirement. Throughout Europe, a type-tested LPG heater may be used while driving (according to Directive UN ECE R 122) if the system includes this regulator with an appropriately configured gas installation. National regulations must be observed.


Question

Do Truma LPG heaters require maintenance?

Answer

No.

However, with heaters that are supported by fans, we recommend that you clean the heat exchanger and the fan wheel fins with a paintbrush or vacuum cleaner before winter.

If the heater has an auto ignitor, we recommend that you replace the batteries about every two years or if the ignition frequency becomes slower. Use only batteries that are heat proof and that do not leak.


Question

Does the Truma heater S 3004 have different dimensions to the previous model Truma S 3002?

Answer

Yes, the dimensions have changed.

Pay special attention to the red highlighted dimensions of Truma S 3004 compared to S 3002. The depth of the floor base in the room is also smaller.


Question

Can the Truma heater S 3004 be installed in place of the old S 3002 and what must be considered?

Answer

Yes, the S 3004 can be installed in the position of the old heater if it is an S 3002 built after 05/96. With older models, the floor cut-out must be changed.

Remember that the control panel carrier is higher due to the new cover and that the cupboard door may have to be modified in some cases. The contour and, hence, the depth of the floor base have also been changed slightly – as a result, you may see the impression of the old base on the floor.


Question

Can I reuse parts from Truma S 3002 in S 3004?

Answer

No.

The design of the S 3004 were changed and made more user friendly. Almost all parts were changed. Therefore, you cannot use the parts from S 3004 for older models. TEB/TN/TEN 1 and 2 fans can still be used with an adapter plate.


Question

Can I reuse the cover from Truma S 3004 in S 3002?

Answer

This is not possible due to the different dimensions and connections and is therefore not approved.

Question

Can I reuse warm air parts and cowls from Truma S 3002 in S 3004 with no modification?

Answer

Apart from cowl top T-1, you can use the warm air parts and cowls without modification.

Question

How do I prepare the Truma S3004 heater for the travel season?

Answer

We recommend that you clean the Truma S heater before starting your holiday.


  • Remove the cover from the S heater.
  • Remove the dust that has accumulated on the heat exchanger or on the base plate.
  • Remove dust on the fan wheel of the Trumavent carefully with a paintbrush or a small brush.
  • Also check whether the exhaust cowl is damaged or contaminated with leaves, for example.
  • Insert the battery in the auto ignitor – if you do not hear ignition sparks or if they are more than a second apart, replace the battery. When replacing the battery, the heater must be switched off. Use only temperature-resistant (+70 °C) leakproof AA batteries. Other batteries may cause malfunctions.


Question

How must the exhaust duct of my Truma heater be installed and what needs to be considered with the exhaust gas system?

Answer

Exhaust ducts must always be laid rising from the Truma heater towards the cowl.

If the exhaust gases from your Trumatic S still pass through an aluminium pipe, replace this with a stainless steel pipe.

Please note that the pipe must be replaced by an expert (e.g. Truma service partner).


Question

Which Truma heaters can I retrofit with the digital CP plus iNet ready control panel?

Answer

The digital CP plus iNet ready control panel can be retrofitted with all Truma Combi heaters. Truma has been producing Combi heaters since 2007, they can be recognised by the grey cover. Since 2013, they have had a black cover.

With older heaters, such as Truma C heaters, the digital CP plus iNet ready control panel cannot be retrofitted.


Question

How does the Truma S heater work?

Answer

The heater is supplied with gas via a special connection (1). It is ignited by a battery-operated auto ignitor (2) in the burner (3). You can see through the inspection glass (4) if the gas has ignited. External air is sucked into the heater through an inlet (5) and is heated by the naked flame in the burner (3). The hot air flows through the S-shaped heat exchanger (6) and exits the system to the atmosphere together with the combustion air through the exhaust duct (7) and the roof cowl (8). This process is 100% safe thanks to the completely enclosed system and the thermoelectric safety pilot. The heat exchanger (6) heats the direct ambient air in the heater housing. It exits through the holes in the cover into the living area and, if necessary, is distributed in the caravan by the fan (14).

The temperature of the heater is infinitely adjustable with the manual knob on the control panel (9). This activates the safety pilot valve (12) via the control panel rod (11). When the required room temperature is reached, a thermostat sensor (13) regulates the gas supply to the burner and reduces it accordingly. The fan is controlled via a second control knob (10).

The Ultraheat additional electric heater (15) is the perfect supplement for everyone who wants additional electric heat and to get the RV nice and warm quickly independently of the gas supply. It heats very quickly and uses the fan of the S heater to distribute the warm air efficiently throughout the caravan.

1 Connection for gas supply
2 Auto ignitor
3 Burner with ignition electrode
4 Inspection glass for flame control
5 Combustion air inlet
6 Heat exchanger
7 Exhaust duct
8 Roof cowl
9 Fan control knob
10 Heater control knob
11 Control panel rod
12 Safety pilot valve
13 Thermostat sensor
14 Fan
15 Ultraheat


Question

I have a Carver 1800SC heater in my 1998 Bailey Ranger caravan, and the piezo ignition stopped working this morning. Is it possible to get a replacement, or does it mean a new heater?

Answer

Regret the igniter on this heater is obsolete and a scrap yard may be your only hope. The replacement heater is the TrumaS3004.
